Extreme Ultraviolet Lithography - Market Share Analysis, Industry Trends & Statistics, Growth Forecasts (2026 - 2031)

According to Mordor Intelligence, the extreme ultraviolet lithography market size in 2026 is estimated at USD 25.93 billion, growing from the 2025 value of USD 23.71 billion, with 2031 projections showing USD 40.54 billion, growing at a 9.35% CAGR over 2026-2031.

This report is Segmented by Product Type (Light Sources, Mirrors / Optics, and More), End-User Type (Foundries, and Integrated Device Manufacturers (IDMs)), Technology Node (7 Nm and Above, 5 Nm, and More), Light-Source Technology (Laser-Produced Plasma, Gas-Discharge Plasma, and More), and Geography (North America, Europe and More). The Market Forecasts are Provided in Terms of Value (USD).

Global Extreme Ultraviolet Lithography Market Trends and Insights

Demand for Sub-5 nm Nodes

Mass-production plans for 2 nm chips scheduled for 2025 call for line widths that only EUV exposure can achieve. TSMC has set aside USD 12.3 billion for its EUV tool fleet, a budget that targets 10-15% speed gains or 25-30% power cuts versus 3 nm designs. Smartphone and data-center chip buyers have already queued for those nodes, allowing equipment vendors to lock in multi-year backlogs. As a result, the EUV lithography market enjoys a predictable shipment pipeline that mirrors each successive node shrink.

Accelerated AI/5G/HPC Capacity Build-out

AI accelerators, 5G base-band silicon, and high-bandwidth memory all need tight pitch metallization. TSMC's Q4 2024 revenue rose 37% year-on-year to USD 26.88 billion, illustrating the scale of demand. To keep pace, the company budgeted USD 32-36 billion for capex in 2025, including roughly 60 EUV scanners. Such orders shorten tool lead times and bring smaller suppliers-pellicle, mask blank, and resist vendors-into the growth loop of the EUV lithography market.

USD 150 m+ System Cost and Fab Retrofit Complexity

Baseline EUV scanners list at roughly USD 150 million, and high-NA units more than double that figure. Fabs also upgrade clean-room airflow, vibration damping, and power distribution. Smaller foundries struggle to amortize such outlays, risking a technology gap that narrows potential customers for the EUV lithography market. Dual-lane operations, where DUV and EUV run in parallel, further enlarge capital budgets.

Other drivers and restraints analyzed in the detailed report include:

1. Government Semiconductor Subsidy Programs
2. Transition to High-NA EUV Platforms
3. Single-Vendor Dependency and Supply-Chain Bottlenecks

For complete list of drivers and restraints, kindly check the Table Of Contents.

Segment Analysis

Light sources accounted for 45.85% of the EUV lithography market size in 2025, underscoring their status as the most expensive subsystem in a scanner. Current laser-produced-plasma (LPP) modules convert CO2-laser pulses and tin droplets into 13.5 nm radiation, but sub-5% conversion efficiency continues to spur research into free-electron alternatives. High average power also drives upgrades such as advanced collector-mirror coatings and debris filters, with service contracts that guarantee power stability, adding annuity revenue for suppliers.

Pellicles are the fastest-growing product, with an 17.9% CAGR projected through 2031. Carbon-nanotube membranes now deliver 97-98% transmittance and withstand 1,000 W exposure, a step change from earlier silicon-nitride films. Major foundries have cleared CNT pellicles for 2 nm process flows, opening a replacement cycle in which every mask layer needs protection; rising scale is already trimming unit cost.

Foundries accounted for 52.75% of the EUV lithography market in 2025 because fab-less customers rely on contract manufacturing. Their specialization lets them order scanners in batches, lock in service capacity, and co-develop processes with tool suppliers. TSMC alone controlled 56% of installed EUV exposure capacity, translating geographic clustering in Taiwan into supply-chain efficiencies and learning-curve cost reductions.

IDMs, however, are expanding faster at a 13.6% CAGR. Intel's IDM 2.0 model reopens its fabs to external clients while adding High-NA capacity reserved through 2025. Subsidy grants lower its effective capital cost, narrowing the unit-cost gap with pure-play foundries. As IDMs upgrade to gate-all-around transistors, they internalize design-process feedback loops, an advantage that should lift their share of the EUV lithography market over the decade.
